| CPU | Model: Rockchip RK3328 Number of Cores: Quad-Core Cortex-A53 Frequency: 4 x Cortex-A53 Up to 1.3GHz |
| Memory | RAM: 1GB DDR4 |
| Storage | MicroSD Slot: MicroSD x1 for external storage up to 128GB |
| Connectivity | Ethernet: Gbps Ethernet x1 USB 3.0 to Gbps Ethernet x1 |
| USB | USB 2.0 Host x1: USB Type A USB-C x1: Power input(5V/2A) and Slave |
| Pin-header | Serial Debug Port x1: 2.54mm pitch 3pin-header(3.3V TTL) |
| LED | SYS LED(Red) x1 WAN LED(Green) x1 LAN LED(Green) x1 |
| Button | User button x1 |
| Working Temperature | 0℃ to 80℃ |
| Power | DC 5V/2A |
| OS Support | FriendlyWrt 24.10 FriendlyWrt 23.05 FriendlyCore Focal Lite (Base on Ubuntu 20.04) Buildroot Debian 11 Core OpenMediaVault Alpine-Linux |
| PCB | 6 Layer |
| Weight | 150g（With Case) |
| Dimension | 55.6x52 mm |
Related Resources
WIKI: http://wiki.friendlyelec.com/wiki/index.php/NanoPi_R2S
| Hardware Spec | |
| CPU: | Model: Rockchip RK3328 Number of Cores: Quad-Core Cortex-A53 Frequency: 4 x Cortex-A53 Up to 1.3GHz |
| DDR4 RAM: | 1GB |
| Network: | Internal 10/100/1000M Ethernet Port x 1 USB3.0 converted 10/100/1000M Ethernet Port x 1 |
| USB Host: | USB 2.0 Host x1: USB Type A USB-C x1: Power input(5V/2A) and Slave |
| Debug Serial Port/UART0: | 3.3V TTL, 3-pin 2.54mm pitch connector |
| Buttons | User button x1 |
| microSD Slot: | 1 |
| LED: | 3 |
| PCB Dimension: | 55.6 x 52mm |
| Power: | DC 5V/2A |
| Working temperature: | 0℃ to 80℃ |
| Software Features | |
| OS Support | FriendlyWrt 21.02.1 (64-bit) FriendlyCore Focal Lite (Base on Ubuntu 20.04) |
