| CPU | Model: Rockchip RK3328 Number of Cores: Quad-Core Cortex-A53 Frequency: 4 x Cortex-A53 Up to 1.4GHz |
| Memory | RAM: 1GB DDR4 |
| Storage | MicroSD Slot: MicroSD x1 for external storage up to 128GB Flash: 32GB eMMC 5.1 Flash |
| Connectivity | Ethernet: 1 x Internal Gbps Ethernet x 1，RTL8211F chip 1 x USB3.0 converted Gbps Ethernet.RTL8153B chip |
| USB | 2 x USB 2.0 Host USB-C x 1:5V power input and USB update in maskrom mode USB-C x 1: onboard USB to Debug UART converter, 1500000bps bauds |
| Pin-header | Serial Debug Port x 1: 2.54mm pitch 3pin-header(3.3V TTL) |
| LED | 1 x SYS LED(Red) 1 x WAN LED(Green) 1 x LAN LED(Green) |
| Button | 1 x GPIO Button 1 x Maskrom mode Button |
| Working Temperature | 0℃ to 70℃ |
| Power | DC 5V/2A |
| OS Support | FriendlyWrt 24.10 FriendlyWrt 23.05 FriendlyCore Focal Lite (Base on Ubuntu 20.04) Buildroot Debian 11 Core OpenMediaVault Alpine-Linux |
| Kernel version | Linux-6.1-LTS U-boot-2017.09 |
| *The firmware is continuously updated, refer to the actual version provided by the WiKi. |
| PCB | 6 Layer |
| Weight | 145g（With Case) |
| Dimension | 62.5 x 63.5 x 30 mm(with Case) |
Related Resources
WIKI: https://wiki.friendlyelec.com/wiki/index.php/NanoPi_R2S_Plus
| Hardware Spec | |
| CPU: | Model: Rockchip RK3328 Number of Cores: Quad-Core Cortex-A53 Frequency: 4 x Cortex-A53 Up to 1.4GHz |
| RAM | AM: 1GB DDR4 |
| Connectivity: | Ethernet: 1 x Internal Gbps Ethernet x 1，RTL8211F chip 1 x USB3.0 converted Gbps Ethernet.RTL8153B chip Optional M.2 SDIO Wi-Fi |
| Storage: | 32GB eMMC 5.1 Flash |
| USB Host: | 2 x USB 2.0 Host 1x USB-C :5V power input and USB update in maskrom mode 1 x USB-C : onboard USB to Debug UART converter, 1500000bps bauds |
| Debug Serial Port/UART0: | Serial Debug Port x1: 2.54mm pitch 3pin-header(3.3V TTL) |
| Buttons | 1 x GPIO Button 1 x Maskrom mode Button |
| microSD Slot: | MicroSD x1 for external storage up to 128GB |
| LED: | 1 x SYS LED(Red) 1 x WAN LED(Green) 1 x LAN LED(Green) |
| Power: | DC 5V/2A |
| Working temperature: | 0℃ to 70℃ |
| Software Features | |
| Kernel version | Linux-6.1-LTS U-boot-2017.09 |
| OS Support | FriendlyWrt 21.02 FriendlyWrt 23.05 FriendlyCore Focal Lite (Base on Ubuntu 20.04) Buildroot Debian 11 Core OpenMediaVault Buildroot |
